805 D4 SATIN

null

Diamond Tweeter
Solid body Tweeter-on-Top
Continuum™ Cone Bass / Mid
Anti-Resonance Plug
Matrix™
Flowport™

選択： Quality

カラーバリエーション：

Black White ROSENUT WALNUT

数量

在庫状況:

Item Unavailable

販売店を探す

Black White ROSENUT WALNUT

805 D4 SATIN

805 D4 SATIN

Black White ROSENUT WALNUT

805 D4 SATIN

詳細と仕様

Size & weight

Net weight 15.55kg (34.3 lb)
Dimensions Height: 440mm (17.3 in)
Width: 240mm (9.4 in)
Depth: 373mm (14.7 in)

Finishes

Cabinet finishes Gloss Black
White
Satin Rosenut
Satin Walnut
Grille finishes Black
Grey
Black
Grey

Technical details

Technical features Diamond tweeter
Solid body Tweeter-on-Top
Continuum™ cone bass/mid
Matrix™
Anti-Resonance plug
Flowport
Description 2-way vented-box system
Drive units 1x ø25mm (1in) Diamond dome high-frequency
1x ø165mm (6.5in) Continuum cone bass midrange
Frequency range 34Hz to 35kHz
Frequency response 42Hz to 28kHz (+/-3dB from reference axis)
Sensitivity 88dB (on axis at 2.83Vrms at 1m)
Harmonic distortion 2nd and 3rd harmonics (90dB, 1m on axis)
<1% 90Hz – 20kHz
<0.3% 120Hz – 20kHz
Nominal impedance 8Ω (minimum 4.6Ω)
Recommended amplifier power 50W – 120W into 8Ω on unclipped programme
Max recommended cable impedance 0.1Ω
